SounDigital EVO5 2CH 400RMS Amplifier

The SounDigital EVO5 2CH 400RMS Amplifier (400.2 EVO 5 – 4 OHMS) is the perfect compact yet powerful solution for enhancing your car’s audio system. Delivering up to 400 watts RMS in bridged mode, this 2-channel amplifier ensures clean and efficient sound across the full frequency spectrum, this amplifier provides high performance without straining your vehicle’s electrical system.

Key Features:

• 2-Channel Output: Ideal for stereo or bridged mono use, providing flexible audio configurations.
• Power Output: 2 x 200W @ 2Ω, 2 x 132W @ 4Ω; Bridged: 1 x 400W @ 4Ω, 1 x 264W @ 8Ω.
• Frequency Response: 10Hz ~ 20kHz for full-range clarity.
• Built-in Filters: Low-pass and High-pass filters set at 80Hz for accurate sound tuning.
• Efficiency: High total efficiency of 88%, minimizing power waste.
• Signal-to-Noise Ratio (SNR): 90dB for crisp, noise-free audio.

Specifications:

• Low Pass Filter: 80Hz
• High Pass Filter: 80Hz
• Operating Voltage: 8V ~ 16V
• Input Sensitivity: 0.2V ~ 4V
• Current Draw (Music): 18A
• Current Draw (Resistive Load): 36A
• Damping Factor: 200
• Stereo Channel Min. Impedance: 2Ω
• Bridge Min. Impedance: 4Ω
• Recommended Fuse (Music): 20A
• Recommended Battery (Min.): 35Ah

Note: Manufacturers warranty is void if damaged due to failure in installation or power surge. Professional installation is required. For warranty, invoice/certificate from installer is mandatory.
